ZW-40 JOKI Concrete Pump

ZW-40 is a lightweight, compact, road-towing trailer pump. Its combination of
powerful pumping, at 40m³/hour, and small size make it perfect for contractors
undertaking multiple pours in a day. In length and in width, it can pump up to
30mm concrete at a horizontal reach of 450-500m and a vertical reach of 180m
(dependant on concrete quality, slump and aggregates).
Model ZW-40 JOKI Trailer Mounted Concrete Pump
Concrete output/m³ 30-40
Concrete Pressure/Mpa 13
Hydraulic Pump Output/cc 112
Horizontal Pumping Distance/m 450-550
Vertical Pumping Distance/m 180
Power 45Kw motor or 56Kw Diesel Engine
Concrete Cylinders/mm 160*1000
Maxinmun Aggregate/mm 30
Hydraulic Oil Capacity/L 200L
Outlet Size/mm 100(80)
Dimensions/mm 4000*1500*1550
Weight/Kg 2200

Minimum Order: 1 sets
