ZW-30 Diesel Concrete Mixer Pump JOKI

Electric motor or Diesel motor 2 options. Concrete output: 15-20 m³/h
The JOKI ZW-30 concrete pumps as supplied by Qijiu come in an array of outputs
ranging from 15 cubic meters to 20 cubic meters per hour over distances of
260-350m. Our trailer-mounted concrete pumps offer the ideal solution for
placing concrete in hard–to-access areas because of their compact size, they
can also be used as an alternative to truck-mounted concrete pumps on larger
pours that require a slower output rate.
Model ZW-30
Concrete output/m³ 15-20
Concrete Pressure/Mpa 12
Hydraulic Pump Output/cc 80
Horizontal Pumping Distance/m 260-350
Vertical Pumping Distance/m 100-120
Power 37Kw motor or 44Kw Diesel Engine
Concrete Cylinders/mm 140*750
Maxinmun Aggregate/mm 30
Hydraulic Oil Capacity/L 150L
Outlet Size/mm 100(80)
Dimensions/mm 4000*1200*1400
Weight/Kg 1800

Minimum Order: 1 sets
