ZM2114 Process Control Measurement Meters Trainer

In order to improve the theory and hand on technical level and actual operation
skills of technical workers, strengthen the workers in the new form under the
condition of competition ability to rapidly improve equipment maintenance and
repair operator site ability to deal with problems, the enterprise introduced a
“process control equipment fault diagnosis and maintenance skills training
platform". This training platform by the controlled object (stainless steel
frame) and control system (mesh plate) composition. Controlled object contains a
power system, water tank, storage tank, pressure transmitter, turbine flowmeter,
variable pressure transmitter, Pt100 and K dividing thermocouple, electric
control valve, solenoid valve, piping and valves, etc.,
