Yingdong Stadium

The stadium was designated as the Asia Games'basketball competition stadium,
the hardware and software facilities of the stadium run thorough transformation
to comply with the high-grade requirements of stadium standard set by GAGOC.
The designed HVAC ductwork system was traditional GI ducts, but the solution
encountered some difficulties.

The stadium inner space is 22m and is an all-steel construction structure. If
it used traditional stadium ventilation, hundreds of tons crossed metal duct
not only affect overall aesthetics but also add load-carrying to the roof, and
take the ball nozzle outlets into account, it will greatly increase the total
construction cost. The project leader finally decided to select DurkeeSox®
fabric duct to replace traditional GI ductwork.



DurkeeSox® Technic Center referred to the actual situation and designed 3 main
fabric air ducts (16m in length) which perpendicular to the ground and each
main duct connects to 2 branch ducts(1067 mm in diameter), the 6 branch ducts
form a closed-type hexagon. The DurkeeSox® fabric ducts with multi-line leaser
cutting orifices separately supply air to the spectator stand, media stand, and
basketball court, the ducts covered a larger area with lower airflow velocity,
no noise and even & comfortable airflow, also the aesthetic appearance of ducts
is in harmony with the construction structure as well as save total
construction cost (lightweight fabric duct will significantly decrease load-
bearing to roof).

Meanwhile, the suspension system of DurkeeSox® air dispersion system is a cable
quick suspension system, it is convenience to installation as well as
maintenance processes, and these are directly lower HVAC ductwork system cost.
Besides, selected grey fabric ducts to well match the surrounding decoration
and highlight the aesthetic factor of our fabric duct systems.

DurkeeSox® fabric air dispersion system solution met all requirements of the
project and the airflow effect is good, our system passes the acceptance once
after installation.
Durkeesox, invested by US-registered Durkee International, is a global high-
tech enterprise with a focus on HVAC/R industry. As a member of the United
States Green Building Council (USGBC), Durkeesox has established 2
manufacturing factories (China and America) and 3 sales and service centers
(China, Asia, and America). In the past decade, Durkeesox has become the
fastest-growing company, largest fabric air dispersion system supplier in the
industry and the leading brand in the Asian market.
