YIHUA 1000B 3-IN-1 Infrared BGA Rework Station

YIHUA 1000B / 1000A 3-IN-1 Infrared BGA Rework Station: SMD Hot Air Gun +
540W Preheating Station + 75W Soldering Irons, YIHUA 1000B personal BGA
rework station 3 in 1 SMD Hot Air Gun+75W Soldering Irons+540W Preheating
Station. YIHUA 1000B Soldering rework station: powerful electronics repairing
machine for all kinds motherboard / repair, YIHUA 1000B 3-IN-1 Infrared BGA
Rework Station for Personal Repair Shop: motherboard / laptop / mobile phone
motherboard repair

Feature:
1. Using the new SAMSUNG microcomputer processor PID programmable temperature
control technology and uses an infrared source and optics to target heat to
individual components without dislodging other SMT parts by way of eddies air
currents.
2. Adopt infrared weld technology which independent exploration , infrared
penetration strength , components uniform heating , beyond the traditional
hot air heating vowed to prevent blow off the IC surrounding small
components.
3. Technician focused infrared heat is easy to target most component
removal/replacement and re-work.
4. Infrared heat source bulbs are long-lived , un-expensive and easily
replaced.
5. Has bright delicate , low voltage LED lighting , safety and energy
conservation.
6. It has External Sensor Temperature control mode , that is detected by the
sensor IC surface temperature control temperature , this function is good for
freshman operation , it’s safe way protect components .
7. MountTechnology (SMT) components 15-35cm in size.
8. This machine has 540W heating system , widely to 120mm*120mm.
9. Preheating plate color is black , from the photics point of view , black
color easy to absorb heating , shorten the warm-up time.
10. Powerful human function design , with the following functions
A. Temperature correction function Correction of temperature range
-50°C~+50 °C ( Infrared lamp analog value 580 ).
B. Celsius / Fahrenheit temperature display function
11. This machine also has soldering iron function , if you have the device ,
you can used for all of the components solder , desoldering , preheating ,
repair all components , especially Micro BGA components.

Minimum Order: 1 pieces
