WEDGE WIRE IN-LINE MIXERS

wedge wire In-line Mixers are very effective in wells of this type since
they can be manufactured with very small slot size and yet still maintain
the necessary open area to minimize friction head loss. Most continuous wire
wrap screen is manufactured from stainless steel rather than carbon steel in
order to avoid problems which often leads to accelerated corrosion.
APPLICATION FOR WEDGE WIRE IN-LINE MIXERS:
Used in industries such as Sugar, Coal Mining & Quarrying, Mineral
Processing, Cement, and Industrial & Urban Effluent Treatment etc.
Used as a pre-filter in urban & industrial waste treatment plants to improve
the performance of the clarifier by dramatically reducing the load.
Used for fiber removal in Starch industry.

ADVANTAGES FOR WEDGE WIRE IN-LINE MIXERS:
The Wedge Wire Screen is composed of rod strips and V shaped wires through
manufacturing on specialized welding machine. The rib strips and V shaped
wires will be welded by resistance welding, has enough welding strength,
equally slot gap, high corrosion resistance, large filter area, good
permeability, simple structure

PRODUCT CHARACTERISTICS FOR WEDGE WIRE IN-LINE MIXERS:
1. It has high mechanical strength, can bear large pressure drop.
2. It has equal slots for filtering, can form equally distributed filter
cake, easy to clean for reuse.
3. The wedge type slot can improve backflushing and regeneration
performance.
4. It has resistance to pressure, temperature, aging, corrosion, can be
applied for different kinds of fluid.

CUSTOMIZED DESIGN FORWEDGE WIRE IN-LINE MIXERS：
The design is customized to your demands;
Slot opening from 50 micron up to 2000 micron
All API and ANSI pipe sizes are available
Customized construction:
Lower V-wires for reduced OD
Higher support rods for more standoff
Customized end-fittings and threaded connections
Fixation of screen by welding or shrink fitting of end-rings to the base-
pipe

Minimum Order: 1 metres
