Water Treatment Chlorine Rotary Tablet Press Machine 10000pcs/H 25mm Diamet

Water Treatment Chlorine Rotary Tablet Press Machine 10000pcs/h 25mm
diameter



Introduction:

The model ZP40-11 is a medium sized rotary tablet press machine. It has been
widely used in chemical, food, health beauty and other areas. ZP40-11 rotary
tablet press is a R&D product from our company. It is suitable to press all
kinds of granular materials into tablets of round or nun-round shapes. It is
popular in bigger tablet production (eg: Dia=20-40mm), such as animal
medicine, art use block. Machine body is packaged by stainless steel and its
tablet pressing room uses a new fully enclosed structure of Plexiglass,
bright and of good appearance.

One of its typical Applications is for 20g chlorine tablet production. Just
in china, more than 60 sets of our ZP40-11 machines are used to produce
20g/30g chlorine/1-inch Tri-chlor/1-inch swimming pool chlorine tablets. For
example: Hebei Jiheng Chemical and Tai’An Huatai Chemical are using our
ZP40 series machines.





Characters:

* high working pressure, guarantee the hardness of finished tablets.

* Speed variation by inverter.

* Easy and quick assembly and dismantling of hoppers, feeders and dies for
cleaning and product replacement purposes.

* Transparent window of plexiglass, easily check tablet production and
clean.

* Therotary tablet machine has adjustable wheels. Machine speed and depth of
fill can be adjustable according to real production. Also easy to operate.

* Simplicity of operation, operator safety and easy to maintenance

* Specially designed for pharmaceutical, Veterinary, chemical, plastic,
ceramics, Powder metals and other specialized industries.





Following is the specification of ZP40-11 Rotary Tablet Press Machine for
your reference.



Model ZP40-11 Rotary Tablet Press
Dies 11sets
Max pressure 400Kn
Dia of Tablet 20-40mm
Depth of Fill 43mm
Thickness of Tablet 15-22mm
Turret Speed 1-15r/min
Production Capacity For nun-round shape, 7500-10000pcs/h
For round tablets, speed is higher, 15000pcs/h.
Motor 7.5Kw 3P380v/50hz(customized)
Overall Size 900*900*2200 mm
Net Weight 2800kg
