Voltage Type Two Axis Tilt Sensor

Introduction
ER-TS-5240VO Voltage Two Axis Tilt Sensor is a low-cost biaxial voltage output
inclination sensor with output voltage 0~5V, 0.5~4.5V, and optional 0~10V. It
is mainly aimed at the application market where volume and cost are highly
limited.
Due to the built-in micro-electro-mechanical production process inclination
device, the product is small in size, low in power consumption, industrial-
grade working temperature is -40~+85℃.
With the non-contact measuring principle, can output the current attitude and
inclination in real time, easy to use and no need to retrieve the relative
changes of the two surface installation. The product has the characteristics of
small volume, anti-external electromagnetic interference, strong ability to
withstand shock, which is the ideal choice of industrial equipment, platform
attitude measurement.

Features
Two axis tilt monitoring
Full range accuracy 0.3°, resolution 0.05°
Output 0~5V, 0.5~4.5V, 0~10V optional
Wide voltage input DC 9~36V
Wide temperature working -40~+85℃
Measuring range: 0~±90°(optional)
High vibration resistance>2500g
IP67 protection
Industrial design
Small volume (55*37*24mm) (customizable)

Applications
Intelligent power transmission line
High altitude working vehicle
Tractor, deep farming machinery
Mining machinery, oil logging equipment
Medical equipment
Hydraulic lifting platform
Inclination monitoring
Angle control of various construction machinery
Inspection of bridges and dams
