Vertical Ampoule Bottle Making Machine

Vertical ampoule bottle making machine Technical Parameter

Vertical ampoule production line has a high degree of automation, compact
structure, high output, reasonable layout and low energy consumption. It can
produce 1ml, 2ml, 3ml, 5ml, 10ml, 20ml ampoule of different diameters.
Installation,maintence and training services will be warmly supplied.

Item Unit Parameter
Weight for Machine KGS 3000
Plate Rotation Motor KW Motor Gearbox 1.5KW
Chuck Rotation Motor KW Motor Gearbox 1.5KW
Daily power consumption KWA 3KWA/Day
Gas consumption
Natural Gas M³ 2.5-10 M³
Oxygen M³ 1-4 M³
Air 100ml 23-100 M³
Gas Pressure
Coal Gas gr 200-250g
Oxygen gr 200-250g
Air gr 300-350g
Ampoules Output by Machine
1-3ml ampoule output Pcs/hour 5000pcs/hour
5ml ampoule output Pcs/hour 4600pcs/hour
10ml ampoule output Pcs/hour 4200pcs/hour
20ml ampoule output Pcs/hour 3800pcs/hour
