Two/Four spark igniter BW-DH019
Two/Four spark igniter BW-DH019
Basic Information
This controller of which rated operating voltage is 1.5V can control two sparks
by one single switch. The sparking is on with switch being connected and the
sparking is off with switch being unconnected.
spark igniter Baiwei Functional Description
HV output is controlled by the sparking switch. HV output is on with switch
being connected.
Technical Parameter
No. Item Specification
1 Rated operating voltage 1.5VDC
2 Operating voltage range 1.0—1.6VDC
3 Current ≤380mA(1.6V)
4 Sparking rate ≥3Hz（1.6V）
5 Sparking gap ≥6mm
6 Sparking energy ＞1.0mJ
7 Sparking cycle ≤400ms
8 Sparking pulse width ≥12μs
9 HV output ≥(20-24)kV@20pF
10 Operating temperature -20℃—+70℃
11 Storage temperature -20℃—+80℃
12 Operating humidity ＜95%
13 Operating life ＞100000 cycles
Minimum Order: 500 pieces
)
