Three-Phase & Single-Phase Transformer Winding Frequency Response Analyzer

1. Winding deformation test based on different standards of sweeping
frequency
method.
2. It can measure the phase frequency curve and amplitude frequency curve of
each winding of the transformer.
3. It can cyclically test of phase and amplitude of transformer windings at
fixed frequency.
4. Analyze the transformer amplitude-frequency curve based on IEC standard.
5. Built-in non-dropout memory, winding deformation can be saved for 40
groups.

1. Sweeping frequency method to measure winding deformation.
Scan frequency range: 10HZ-1MHZ (DLT911-2016 0.5KHZ interval linear scan)
20HZ-2MHZ (GB/T-1094.18 IEC60076-18:2012 segmented
scanning)
10HZ-10MHZ (GB/T-1094.18 IEC60076-18:2012
segmented scanning)
1KHZ -1000KHZ_1.0(Linear scan 1KHZ interval PC side
available)
1KHZ -1000KHZ_0.5(linear scan 0.5KHZ interval avaiable4
for Pc)
1KHZ -2000KHZ_1.0(linear scan 1KHZ interval available
for PC)
1KHZ -2000KHZ_0.5(linear scan 0.5KHZ interval available
for PC)
100HZ-1000K(Segmented scan PC available 1441 points):
100HZ-1KHZ 5HZ interval 180 points
1KHZ-10KHZ 50HZ interval 180 points
10KHZ-100KHZ 500HZ interval 180 points
100KHZ-1000KHZ 1KHZ interval 901 points
100HZ-2000K(Segmented scan PC available 2441 points)
100HZ-1KHZ 5HZ interval 180 points
1KHZ-10KHZ 50HZ interval 180 points
10KHZ-100KHZ 500HZ interval 180 points
100KHZ-1000KHZ 1KHZ interval 900 points
1000KHZ-2000KHZ 1KHZ interval 1001
Points
Amplitude measurement range: (-100dB) - (+20dB)
Amplitude measurement accuracy: (-40dB) - (+20dB) 0.2dB
(-60dB) - (-40dB) 0.5dB
(-80dB) - (-60dB) 1.0dB
Angle measurement range: (-180°) - (+180°) (10HZ-2MHZ)
Scan frequency accuracy: less than 0.01%
Signal input impedance: greater than 1M Ω(DLT911-2016)
50 Ω(GB/T-1094.18 IEC60076-18:2012)
Signal output impedance: 50 Ω.
Same-phase test repetition rate: 99.5%.
