SUS304 Detergents Powder Pressure Nozzle Spray Dryer

YPG Model Detergents powder Pressure type Nozzle Spray Dryer Machine

1. General description

Spray dryer is suitable for solution, suspension, slurry, paste material,
etc. Liquid material is atomized to small fog drops. And fog drops contact
with hot air directly in the drying tower. Moisture content is evaporated
instantly. So spray dryer features high efficiency, high mass transfer area,
and short drying time, in general it is 5~30 seconds. Operating temperature
can be adjusted according to actual situation, in general inlet air
temperature is 150~500°C. And its automation control degree is control,
environment solution environment can be solved.


2. Features

The machine has high efficiency to collect dust
Without the phenomenon of adhering wall
Energy saving and high efficiency
Particularly it is suitable for thermal sensitive material
Short drying time
SUS304 Detergents Powder Pressure Nozzle Spray Dryer 1
3. Technical parameters

Model

Item

YPG-25 YPG-50 YPG-100 YPG-150 YPG-200 YPG-300 YPG-500 YPG-1000~2000
Water evaporation(kg/h) 25 50 100 150 200 300 500
According to actual situation
Diaphragm pump Power (Kw) 0.35 4 7.5 11 15 22
30
Pressure (Mpa) It can be regulated from 0.6-5. In general, it is 1-3
According to actual situation
Heating source Electricity Electricity + steam Hot air furnace
Diameter of tower (mm) 1300 1800 2400 2600 2800 3200 3800
According to actual situation
