SUNSHINE P-3005A Digital Programmable DC Power Supply

SUNSHINE P-3005A 30V 5A DC power supply for mobile phone repair. Sunshine
digital programmable adjustable 4 bits digital accurate display laboratory
power supply.

Product Features :
The 5A adjustable dc power supply is with high quality and high power
transformer, the machine power is enough, can really achieve the voltage
output 30V, current output 5A, and can accurately set the protection current
size.
4 bit accurate control and display, bring more precise control, and constant
pressure flow protection mode, effective protection of the safety of the
load.
The whole process circuit after the factory more than 10 years of continuous
improvement and innovation, precise control, mature technology, high safety,
stable and reliable by users at home and broad is certainly.
4 built-in temperature control protection circuit, when the machine internal
heating temperature of over 40 degrees, the cooling fan will automatically
run, when the power is connected to load more than the maximum load of the
machine will automatically protect, stop output, effectively protect the use
of power supply safety, extended service life.

Primary Technical Parameter :
Rated working condition
Supply voltage AC220V ±10% frequency (50hz )
Working condition temperature -10°C-40°C, relative humility≤90%
Storage condition temperature -10°C-40°C, relative humility≤80%
Output :
Voltage 0-30V
Current 0-5A
Protection types circuit protection,overload and over high temperature
protection.

Product Specification :
Product Name: NC programmable DC Power Supply
Model: P-3005A
Product Size: 110 (W) *156 (H)*260 (D) mm
Weight: 4.5kg
Output Voltage: 0-30V
Output Current: 0-5A
Number of channels: single channel
Output resolution: Voltage: 1mV Electric current: 1mA
Display Type: Voltage/Electric current/4 digit digital display
Load Effect: Voltage: ≦0.01%+2mV Electric current: ≦0.02%+10mA
Power supply effect: Voltage: ≦0.01%+3mV Electric current: ≦0.02%+3mA
Set Accuracy: Voltage: ≦0.5%+20mV Electric current: ≦0.01%+ 10mA
Ripple: Voltage: ≦2mVrms Electric current: ≦3mArms
Output Temperature Coefficient: Voltage: ≦150ppm Electric current: ≦150ppm

Warranty :
1 Years warranty.
As usual, the shipping fee is high. If return China to repair, is not worth
the money.
So we could support technology and give you the spare parts along with the
product.
