StarFire SG1024/XSA Printhead

The StarFire SG1024/XSA is purpose-built for today’s demanding high-speed
scanning and single-pass industrial systems designs. It is an easy to
integrate, high performance, drop-on-demand printhead for single-color
operation at resolutions up to 400 dpi. A robust and repairable
construction makes it ideal for Textile, Wide Format and Commercial
Printing and Decorating


Each SG1024/XSA printhead has 1024 independent channels arranged in 8 rows
in a single nozzle plate for resolutions up to 400 dpi. All 1024 nozzles
can be fired.

The StarFire SG1024/XSA is a compact, self-contained unit built to
withstand demanding industrial textile and other applications. It uses
field proven materials to deliver consistent output over a long service
life with continuous ink re-circulation and single color operation at 400
dots-per-inch. Equipped with a single replaceable metal nozzle plate that
is designed to withstand abrasion and resist damage. The unit is compatible
with solvent, UV-curable and aqueous ink formulations.


Features
Robust and repairable construction
12 picoliter nominal drop size
1024 individually addressable jets
Incorporate VersaDrop™ binary and grayscale jetting
Continuous ink recirculation with RediJet®
Removable/replaceable collar mounted, coated metal nozzle plate
