Stainless Steel Checkered Plate Five Bar Type

Five Bar Stainless Steel Checkered Plate offers excellent physical and chemical
properties as well as functional anti-slippery properties. Stainless steel
checkered plate sheet with five bar pattern has a bigger density of embossed
pattern compared with single bar, two bar or three bar designs, hence, this
kind of checkered ss plate offers superior anti skidding force over checkered
plates with less bar number pattern. Stainless steel checkered plate five bar
sheets are mainly used for food industry equipment, ordinary chemical
equipment, building, householdeffects, dinnerware, cupboard, water heater,
bathtub and architectural designs.

Features:
1. Corrosion resistance and alkaline resistance.
2. Strong.
3.Antirust
4.High temperature resistant 1000-1200 degrees.
5. A variety of patterns both for anti skidding and decorative effects.

Standard followed: AISI, ASTM, JIS, SUS,GB

Material:
SUS304 304L 316 316L 317 317L 309S 310 430, etc.

Plate or Sheet Width:
1219mm,1250mm,1500mm,2000mm or as request
Plate or sheet thickness: 0,3mm-12mm
Length: 2000mm,2438mm,3000mm,6000mm or as request
