Sintered Powder Filter Tube

Sintered Powder Filter Tube Technical Parameter
Raw Material: SS 316L,Titanium
Filter Rating Range: 0.22 Micron ~ 100 Microns
Filter Efficiency: > 99.99 %
Operation Temperature: ≤ 816 ℃
Outside Diameter: 12 mm, 18 mm, 20 mm, 25 mm, 30 mm, 35 mm, 40 mm, 50 mm,
60 mm, 65 mm, 70 mm, 80 mm, 90 mm, 100 mm, 130 mm
Length: 5'' (127 mm), 10'' (254 mm), 20'' (508 mm), 30'' (762 mm), 40'' (1016
mm) or others

Sintered Powder Filter Tube Feature
1. Sintered powder filter tube has high porosity
2. Sintered powder filter tube is good for backwash
3. Sintered powder filter tube has high mechanical strength
4. High filter efficiency
5. High dirt holding capacity
6. High temperature resistance
7. High corrosion resistance
8. Long service life

Application
1. Steam filtration (aseptic package, breweries, chemicals, dairies,
electronics, food and beverage, pharmaceuticals, plastic)
2. High temperature gases filtration (highly aggressive gases, nitrogen, carbon
dioxide, compressed air, tank ventilation)
3. High temperature liquid filtration (chemicals, cosmetics, paints, salt and
seawater, syrups, coolants, food and beverage, pharmaceuticals, solvents,
water)
4. Catalysts powders recovery
5. Precoat support filtration

Minimum Order: 1 pieces
