sick sensor WTB16P-24161120A00

sick sensor WTB16P-24161120A00

Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression
Sensing range
Sensing range min. 10 mm
Sensing range max. 1,000 mm
Adjustable switching threshold for background
suppression
100 mm ... 1,000 mm
Reference object Object with 90% remission factor (complies with standard white
according to DIN 5033)
Minimum distance between set sensing range
and background (black 6% / white 90%)
25 mm, at a distance of 400 mm
Recommended sensing range for the best performance
100 mm ... 400 mm
Emitted beam
Light source PinPoint LED
Type of light Visible red light
Shape of light spot Point-shaped
Light spot size (distance) Ø 6 mm (500 mm)
Maximum dispersion of the emitted beam
around the standardized transmission axis(squint angle)< +/- 1.0° (at Ta = +23
°C)

Enclosure rating IP66 (EN 60529)
IP67 (EN 60529)
IP69 (EN 60529) 1)
Ambient operating temperature –40 °C ... +60 °C
Ambient temperature, storage –40 °C ... +75 °C
Shock resistance 50 g, 11 ms (25 positive and 25 negative shocks per axis, for X,
Y, Z axes, 150 shocks in total
(EN60068-2-27))
50 g, 6 ms (5,000 positive and 5,000 negative shocks per axis, for X, Y, Z axes,
30,000 shocks
in total (EN60068-2-27))
Vibration resistance 10 Hz ... 2,000 Hz (Amplitude 0.5 mm / 10 g, 20 sweeps per
axis, for X, Y, Z axes, 1 octave/min, (EN60068-2-6))

Please contact me to get more information and models

Email:Mia@cwlyautomation.com
VK/W , hatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com

ECLASS 5.0 27270904
ECLASS 5.1.4 27270904
ECLASS 6.0 27270904
ECLASS 6.2 27270904
ECLASS 7.0 27270904
ECLASS 8.0 27270904
ECLASS 8.1 27270904
ECLASS 9.0 27270904
ECLASS 10.0 27270904
ECLASS 11.0 27270904
ECLASS 12.0 27270903
ETIM 5.0 EC002719
ETIM 6.0 EC002719
ETIM 7.0 EC002719
ETIM 8.0 EC002719
