series two dimensional vacuum weak magnetic automatic stage

Specification:
Order products, delivery time 35-40 days

Product parameters:

Model number unit PT-ZK150×150
journey mm 150x150
Body material —— Aluminium alloy
Surface treatment —— Polishing degreasing
rail —— Inlet cross roller guide
Maximum uniaxial velocity mm/s 10
Maximum uniaxial acceleration m/s² 1
Repeated positioning accuracy μm ±0.15
straightness μm ±5
Vacuum degree —— 10-5
flatness μm ±5
orthogonality μm/100mm 10
Drive motor —— Piezoelectric ceramic motor
Maximum center load kg 4
Feedback signal —— TTL
Positioning accuracy μm ±6
Control mode —— Closed loop
Rated current A 0.32
Be self-possessed kg 4.62/4.88
