SCHNEIDER discrete input module 140DDI35300

SCHNEIDER discrete input module 140DDI35300

Range of Product
Modicon Quantum automation platform
Product or Component TypeLow voltage dc discrete input modules
Discrete input number32

Group of channels4
Logic inputPositive (sink)
Discrete input voltage24 V DC
Input voltage limits19.2...30 V
Voltage state 1 guaranteed 15...30 V DC
Voltage state 0 guaranteed-3...5 V DC
Current state 1 guaranteed >= 2 mA at Us = 5.5 V and Uin = 0 V
Current state 0 guaranteed<= 0.5 mA
Addressing requirement2 input words
Input impedance 2500 Ohm
Maximum leakage current 200 mA at Us = 5.5 V and Uin = 4 V
Absolute maximum input 30 V continuous
56 V during 1.3 ms decaying pulse
Response Time
<= 1 ms from state 0 to state 1
<= 1 ms from state 1 to state 0

Please contact me get more information
Email:Mia@cwlyautomation.com
VK/ , Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com

Protection Type
Input protection by resistor limited

Power dissipation
1.7 W + (0.36 x number of points on)

Isolation between group and bus
1780 Vrms for 1 minute

Isolation between group
500 Vrms for 1 minute

Country of originUS
Packing UnitsUnit Type of Package 1PCE
Number of Units in Package 1
Package 1 Height 1.83 in (4.65 cm)
Package 1 Width 6.48 in (16.45 cm)
Package 1 Length 12.19 in (30.97 cm)
Package 1 Weight 14.4 oz (409.2 g)

Contractual warranty
Warranty 18 months

More models
140CPS11100 AC Power Supply 115/230 Vac 3 A Module
140CPS11100 AC Power Supply 115/230 Vac 3 A Module (PV01 or Greater)
140CPS11400 AC Power Supply, 115/230 Vac, 8 A Module
140CPS11410 AC Summable Power Supply 115/230 Vac, 8 A
140CPS11420 AC Summable Power Supply 115/230 Vac, 11 A
140CPS12400 AC Redundant Power Supply, 115/230 Vac 8 A Module
140CPS12420 AC Redundant Power Supply, 115/230 Vac 11 A Module
140CPS21100 DC Power Supply, 24 Vdc, 3 A Module
140CPS21400 DC Summable Power Supply, 24 Vdc, 8 A Module
140CPS22400 DC Redundant Power Supply, 24 Vdc, 8 A Module
140CPS41400 DC Summable Power Supply, 48 Vdc, 8 A Module
140CPS42400 DC Redundant Power Supply, 48 Vdc, 8 A Module
140CPS51100 DC Power Supply, 125 Vdc, 3 A Module
140CPS52400 DC Standalone/Redundant Power Supply, 125 Vdc, 8 A

Please contact me get more information
Email:Mia@cwlyautomation.com
VK/ , Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com

Minimum Order: 1 sets

SCHNEIDER discrete input module 140DDI35300
