Reactor Internals for Radial Flow Reactor & Down Flow Reactor
We design internal internals for gas/liquid / solid hybrid reactors (wedge
wire screen type) in petrochemical applications.

Reactors used in the chemical, petrochemical, and refining industries have
different flow directions. This flow may be radial (Radial Flow) or vertical
downwards (Down Flow). YUANLV has gained extensive experience in
constructing Radial Flow and Down Flow reactor internals.



The technical level of the hydrogenation process mainly depends on the
performance of the catalyst, the performance of the catalyst depends on the
advancement and rationality of the reactor Internals.



Unlike wedge wire screen filter products used in other industries, Johnson
Screen Reactor Internals has strict requirements on raw materials,
production processes, and error control.

Through years of R&D and upgrades, our reactor's internal components can
fully realize the full potential of the reactor.



Radial flow reactor internals
Down flow reactor internals
1) Center pipe

2) Scallops

3) Outer baskets



1) Catalyst support grids

2) Para-Xylene (PX) Grids

3) Outlet collectors

4) Header and laterals

5) Nozzles

6) Candle Filter Elements
