PTFE Architectural Membrane

PTFE Architecture Membrane is made of polytetrafluoroethylene (PTFE) coated
special woven fiberglass membrane which is extremely durable and with high
mechanical strength, Teflon coating provides a chemically resistant surface
which prevent the harm from environmental pollution, offers high and low
temperature resistance, water proof, weather resistant, as well as self-
cleaning performance, PTFE will be bleached by UV light which makes it turn
into a bright white appearance in the long term. PTFE coated glass cloth is
also non flammable which enable it a kind of safe material as architecture
membrane, it is also easy to be fabricated, can be heat-sealed at the seams
and provides a long life span of over 30 years.

Specifications Of PTFE Architectural Membrane

Project Product number
Base cloth glass fiber
Coating PTFE

Colour turns white after sun exposure

Fire-proof level A2


Film thickness 0.3±0.05 0.5±0.1 0.6±0.1


Membrane weightg/㎡ 500±50 600±60 1050±105
Tensile degree Radia（N/5cm） 3000 4500 5000


Weft 2800 4000 4500
（N/5cm）
Degree of tear Radial 160 250 300
（N/5cm）
Weft 110 250 300
（N/5cm）
F(%) 20 10 10

Highlight Of PTFE Architectural Membrane
The coated material has high tensile strength and resist to both high heat
and low temperature, provides superior properties include chemical resistant,
weather resistant, UV resistant and self-clean surface.

Interior membrane is mainly used for acoustic solutions of functional rooms,
this membrane is lighter weight and softer, suitable for museums, offices and
showrooms.

Laminated mesh membrane is the open mesh membrane laminated with FEP film on
both sides, this membrane will have high translucency.

As one of the most professional ptfe membrane suppliers / ptfe membrane
manufacturers / ptfe membrane factory, we provide ptfe membrane material,
ptfe membrane sheet, polytetrafluoroethylene membrane, silicone coated cloth,
etc. For ptfe membrane uses or ptfe membrane price, please feel free to
contact us!

There are many ptfe cloth manufacturers, but we are one of the best choices
for you.
