PTE-S5000 Smart Card Sorting and Ranking Machine

This product is designed for various types of smart cards that comply with
ISO/IEC7816 regulations. It uses visual recognition systems, contact IC
recognition, and non contact IC recognition to read and recognize information
on the card surface or inside the chip. The identified data is matched with the
database memory data information to determine the current card sequence number,
thereby achieving card sorting and ranking.

During the production process, custom smart card that fail inspection and
missing cards will be replaced with specially designed replacement
identification cards. After each unit sorting is completed, a box sorting
identification card will be inserted.

Specifications of PTE-S5000-Smart Card Sorting Machine and Ranking Machine
PARAMETER
Capacity 5000uph
Dimension 3520mmx 880mmx 1920mm
Weight 1400kg
Power Supply 220V, 50Hz, 5KW
Air Supply 0.6Mpa
Noise ＜65dB
Operation Temperature Room temperature: 23℃±3℃
Operation Humidity 50±10％
Communication Interface Ethernet
Adapt to Card Type Supports various ISO ID-1/CR-80 compliant cards such as
PC, PET, PVC, ABS, etc. (53.98 mm x 85.60 mm)

Functions of PTE-S5000-Smart Card Sorting and Ranking Machine
PARAMETER

Card Issuing Unit
1 set of removable card box with a maximum capacity of 500 cards.

Flipping Unit
2 sets, adjusting the card direction to achieve recognition and verification of
card surface information and chip information under different card surface
conditions.

Identification Unit
2 sets, including OCR visual recognition, contact IC recognition, and non-
contact IC recognition. Read and recognize the information on the surface of
the card or inside the chip, and match it with the data in the database to
determine the current card sequence number.

Cache Unit
1 set, cache cards that belong to the current sorting range but do not belong
to the current sorting unit, and have automatic card sending and receiving
function.

Card Sorting Unit
2 sets of sorting turntables, each set storing 250 cards, totaling 500 cards.

Verification Unit
1 set, including OCR visual verification, contact IC verification, and non-
contact IC verification, which can read and verify card surface and chip
internal information.

Card Receiving Unit
Adopting a turntable card receiving structure, equipped with 2 finished card
receiving boxes with a capacity of 500 sheets, which can be automatically
switched; A filling identification card box with a capacity of 200 sheets; A
waste card box with a capacity of 200 sheets

Recycling Box
Recycling cards that do not belong to the current sorting range, with a
capacity of 50 cards.

Advantages of PTE-S5000-Smart Card Sorting and Ranking Machine
WHY
01
It can be applied to various types of smart cards according to ISO/IEC 7816
regulations.

02
Automatically issue identification cards to ensure continuous card sorting in
case of card shortage.

03
The cache unit can cache 2500 cards and supports automatic card sending and
receiving functions.

04
Multiple verification methods can be used to verify the internal and external
information of the card. Ensure that the information inside and outside the
card is consistent and the card sorting preparation is correct.

05
Automatically issue a box splitting identification card, eliminating the need
for re box splitting after receiving the card.

06
An efficient dual rotary sorting mechanism with fast speed and high stability.

As one of smart card solution providers, we can offer kinds of related products
for sale, if you are interested, please contact us.

Minimum Order: 1 sets
