Polish Master Tools

Polish master machines are used to finely machine the copper cylinder for a
fine surface finish degree. After the cylinder finished its fine machining, it
can be installed in engraving machines for patter engraving. The most popular
and advanced machines are the Polish master made in Switzerland Daetwyler
company.
Polish master tools, are precision diamond tools, which are installed on Polish
master machines to process the copper layer on the cylinder. There are
generally three cutters allocated in the Polish master machine—— Rough
Cutter, Fine Cutter and Side Milling Tool. The rough cutter is used for rough
machining copper surface of the cylinder, the fine cutter is used for fine
machining and the side milling tool is for profile machining to the end of the
cylinder. The common polish master machines are 13# and 21# and their
difference is the revolution speed. 13# Polish master machine is low speed and
21# polish master machine is high speed.
Cylinder Preparation Tools Advantages:
We found the possibility to examine the quality of our Polish master cutters to
meet the highest technical requirements.
Blade Test
Our Polish master tools are controlled very strictly with our high-resolution
optical microscope. Only a perfect straight cutting edge can guarantee the
machining quality of rough and fine cutter.
Verticality Test
Place the rough cutter in the measuring apparatus for blade straightness and
verticality to the standard axis, this is to guarantee the surface waviness of
machined cylinder.
Parallelism Test
Place the fine cutter in the measuring apparatus for blade straightness and
parallelism to the standard plane, this is to guarantee the surface waviness of
machined cylinder.
