Plastic Formwork TP60+

TECON Plastic formwork TP60 is recognized as one of the lightest plastic
formwork systems due to its medium size panel design and the application of ABS
(Acrylonitrile Butadiene Styrene). Besides of its light weight, it is also
extremely easy for use even by unskilled workers. Walls, columns, slabs can be
easily and efficiently formed with only a few panel sizes and accessories. We
also provide plastic formwork for concrete walls.

Feature of Plastic Formwork TP60+
Universal application on walls, columns and slabs etc., also modular house with
one pour
Fast and extremely easy to assemble with only a few accessories, no skilled
workers required
Installation without crane assistance due to its light weight
Quick clean with just water

Specification of Plastic Formwork TP60+
High strength and durable panels can reach up to 100 reuse times

Less or even no plaster after strip

Can be also used with foam concrete (light weight concrete)

Up to 3.6m high wall by one pouring, for a maximum fresh concrete pressure of
50Kn/m2

Up to 25cm slab thickness

Different column sizes at 5cm increment start from 20cm

Main Panel size and weight

Description Size Unite weight
Panel TP120/60 1200x600 9.7
Panel TP40/60 400x600 3.1
Panel TP30/60 300x600 2.4
Panel TP25/60 250X600 2.1
Panel TP20/60 200x600 1.9
Panel TP18/60 180x600 1.3

Application of Plastic Formwork TP60+
Medium and small size residential and commercial buildings, basement, columns
and modular houses etc., especially adapt to anti-corrosion needed project.

RELATED PRODUCTS of Plastic Formwork TP60+
LITE Steel Formwork, Adjustable plastic column formwork, Alu Lite formwork

Minimum Order: 1 short tons
