PC020509-153.6V277A (277AH1P48S) LFP277Ah 1P48S Pack

The LFP277Ah 1P48S battery cell module pack is a powerful and reliable power
storage solution. It is a 48V Lithium Iron Phosphate battery with a capacity of
277Ah. It is designed to provide long-term, efficient power storage, with a
maximum continuous discharge current of up to 1000A.. Its robust construction
and designed for long-term use, making it a reliable source of power for any
application.

Specification of PC020509-153.6V277A (277AH1P48S) LFP277Ah 1P48S Pack
Attribute 277Ah
Chemistry LiFePO4
System Voltage nominal 77-772V
System Capacity 277Ah
system Energy 21.4kWh-214.1kWh
System Continous charge current 277A
System Continous discharge current 277A
Temperature range charge 0℃-55℃
Temperature range discharge -20°℃-55℃
Heating System PTC Heater inside each pack
Ingress protection Pack IP67
Ingress protection PDU IP67
Communication protocoll CAN 2.0A/B, SAEJ1939
Pack size Type -L-S-M-LFP-277
Capacity [Ah] 277Ah
Voltage [V] 154.56
Cell config. 48
Modul config. 6x (1p8s)
Energy [kWh] 42.5
Weight [kg] 321.8
Width [mm] 630
Heigth [mm] 240
Length [mm] 1552
Fuse 630A

As one of lithium ion manufacturers, we can offer sorts of lithium ion cells
for sale, anything you need, please contact us.

Minimum Order: 1 sets
