PC020502-192V206A (206AH1P60S) LFP206Ah 1P60S Pack

The LFP206Ah 1P60S Pack is a powerful Lithium Iron Phosphate battery designed
for high-performance applications. It features a 1P60S configuration with 206Ah
of capacity and a voltage range of 14.6V to 16.8V. The rechargeable lithium ion
battery pack is lightweight and has low self-discharge, making it perfect for
solar and other renewable energy systems.

Specification of PC020502-192V206A (206AH1P60S) LFP206Ah 1P60S Pack

Attribute 206Ah
Chemistry LiFePO4
System Voltage nominal 96V up to 768V
System Capacity 206A
system Energy 16.9kWh-135.2kWh
System Continous charge current 1C, 206A
System Continous discharge current 1C, 206A
Temperature range charge 0℃-55℃
Temperature range discharge -20°℃-55℃
Heating System PTC Heater inside each pack
Ingress protection Pack IP67
Ingress protection PDU IP67
Communication protocoll CAN 2.0A/B, SAEJ1939
Pack size Type -L-S-M-LFP-206
Capacity [Ah] 206Ah
Voltage [V] 192
Cell config. 60
Modul config. 6x (1p10s)
Energy [kWh] 33.8
Weight [kg] 302
Width [mm] 630
Heigth [mm] 240
Length [mm] 1496
Fuse 400A

As a lithium ion battery china manufacturer, we can also offer sorts of eco
power car battery for sale, if you are interested, please contact us.

Minimum Order: 1 sets
