Ozone Aging Test Chamber

Introduction
JOEO ozone aging test chamber through the simulation and enhancement of ozone
conditions in the atmosphere, to study the impact of ozone on rubber, and then
determine and evaluate rubber resistance to ozone and aging methods, take
effective anti-aging measures to improve the service life of rubber
products. JOEO Ozone test chamber can be used to test rubber products with
static tensile deformation, such as vulcanized rubber, thermoplastic rubber,
cable insulation bushing, etc. The test pieces were exposed to the airtight air
in the ozone chamber with no light, constant ozone concentration and constant
temperature at a predetermined time, and the surface cracks and other
properties of the test pieces were observed to evaluate the ozone aging
resistance of the rubber. JOEO Ozone test chamber is widely used in product
quality control in measurement quality control. Rubber and plastics; Automobile
production; Wire and cable; Packaging materials; Instruments and meters;
Medical equipment; Civil nuclear energy; Civil aviation; Institutions of higher
learning; Research laboratories; Inspection arbitration, and technical
supervision departments such as rubber products
If you need more models about our test equipment, please reference our chamber-
testing（.）com
Features

Stainless steel inside and outside for ozone testing room
Made of iron with powder coating on the outside
Durable ozone generator (ozone laboratory)
The insulation material is high-density glass fiber cotton
The bottom is a universal round wheel and fixed feet
The window material is multi-layer tempered glass, and the interior is
conductive with chips
Refrigeration compressor oil pressure protection
Lack of reverse phase protection system. Overload protection of circulating fan
motor

Minimum Order: 1 pieces

Click to Enlarge
