OVERVIEW

The Cylone™ aspiration catheter, featuring an end-to-end coil and braid
construction, ensures easy navigation to the M1 and M2 segments and effective
and atraumatic clot removal for patients experiencing acute ischemic stroke

PRODUCT FEATURES
END-TO-END
NITINOL COIL + BRAID DESIGN
Braid improves torsion control and tensile strength of the device.

Aspiration Catheter
Inner coil layer provides superior kink resistance and enhances radial force
under negative pressure resulting in optimized thrombus aspiration ability

Inner coil layer
Excellent navigability

Great pushability

Maintain lumen integrity during navigation and aspiration

Cylone™ Aspiration Catheter
Multi Transition Zones Enhance Force Transmission And Provide Extra Support
Throughout Aortic Arch
Lower bending rigidity at distal segment - Softer distal segment allows Cyclone
to overcome the most tortuous anatomies.

Greater bending rigidity at proximal segment -Excellent pushability and
push/pull control

ORDERING INFORMATION
Product Code Catheter Size OD（in/mm） ID（in/mm） Working length
（French） （cm）
TGC070-06-115 6 0.0825/2.10 0.070/1.80 115
TGC070-06-125 6 0.0825/2.10 0.070/1.80 125
TGC070-06-130 6 0.0825/2.10 0.070/1.80 130
TGC070-06-135 6 0.0825/2.10 0.070/1.80 135
TGC055-05-115 5 0.068 / 1.70 0.055/1.40 115
TGC055-05-125 5 0.068 / 1.70 0.055/1.40 125
TGC055-05-130 5 0.068 / 1.70 0.055/1.40 130
TGC055-05-135 5 0.068 / 1.70 0.055/1.40 135

INDICATION
Cylone™ Aspiration Catheter
The Ton-bridge Aspiration Catheter is intended for use in the
removal/aspiration of emboli and thrombi from selected blood vessels in the
arterial system including the peripheral and neurovasculatures. Moreover, the
Ton-bridge Aspiration Catheter can be used to facilitate introduction of
diagnostic or therapeutic agents.

Minimum Order: 10 sets
