Normal Copper Wire Bunching Machine 34 Zones Adjudtable Winding Pitch

FUCHUAN Normal Copper Wire Bunching Machine 34 Zones Adjudtable Winding Pitch





Quick Details:



Series for Model C normal wire high speed bunching machine and double twist
bunching machine

With high rotation speed, with constant tension from empty bobbin to full
bobbin, with superior quality for twist wire, The machine is driven by
synchronization strap. Only need to change the capstan wheel to change the
pitch. Easy to operate.



Characteristics:



Japan Technology, product in China

1.High rotation speed, max up to 2600rpm, is the 1.6 times than normal
(1600rpm);

2.Use PLC, hysteresis clutch take-up device imported from German, tension
sensor ensure the stable tension and high quality stranding wire, especially
for high quality tight line.

3.Use carbon fiber bow, strong rigidity, uneasy-transformation, small shock,
light weight, reduce air friction for high quality of conductors;

4.Use synchronous belt drive, just to replace the guide wheel to change the lay
distance, easy to operate.

5.Use spindle to calculate meters, only 0.01% error for a certain wire&cable.

6.Use PLC automatically lubricate spindle bearing, avoid injecting too much or
too little grease. Get rid of unnormal noise and worn, cost down for
maintenance.



Specifications:



Equipment models FC-650B-1
Twisting usage It is applied to the twisting of aerospace, medical equipment,
cellphone and ultra conductor(above seven pcs of bare copper wires, tinned
wires, silver jacketed wires and enameled wires),double twisting for core
wires.
Single wire dia(mm) φ0.15-φ1.04
Stranding section area (mm²) 0.35-6.0
Core wire single wire dia φ0.5-φ3.0
Core wire stranding outer dia φ1.0-φ6.0
Pitch(mm) 11.6-100(34zones)
Direction of lay Optional for right or left
Outer dia*bore*outer width
φ630*φ56*475

φ630*φ127*475

M , ax rotating speed 2000(4000twist)
Main motor power 7.5KW
Inverter power 7.5KW
Tension control method Touch screen +PLC+ magnetic powder clutch, it may
ensure the constant tension from empty bobbin to full bobbin
Magnetic powder clutch 5kgf
Protection Machine will automatically brake when wire inside and outside
is broken, the machine will automatically stop when the preset length is
arrived.
Brake mode Electromagnetic brake
Traversing method Rolling ring drive units, winding pitch and breadth are
adjustable

Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
