NBL-4800-II High-speed Semi-automatic External Earloop Welding Machine

NBL-4800-II High-speed Semi-automatic External Earloop Welding Machine Semi
Automatic Mask Production Line Mask Producing Line Distributor

Nobel (Shandong) science and Technology Industry Co., Ltd. was founded in 2013
with a registered

Nobel Non Woven Mask Making Machine Technical Parameters
Equipment Size：3300mm(L)*930mm(W)*1600mm(H)
Capacity： , 60-70pcs/min
Equipment production pass rate：≥95%
Overall Power：≤3KW
Voltage：AC220V 50/60Hz（Please indicate the voltage requirements when
ordering）
Air Pressure：≥0.5-0.6MPa

Equipment Introduction
This equipment is a semi-automatic welding machine for flat mask outer ear
straps. It is suitable for the welding of flat adult mask ear straps. The
recommended mask size is 175 (max) × 95 (max). The loading of the plane masks
requires manual assistance. The masks are transferred to the earloop welding
station through the chain plate, and the earloop are welded by ultrasound.
After the mask is made, it is transferred to the discharge station, and then
collected by the conveyor belt. Others are automatically completed by PLC
control.

Medical face mask machine, also called fully automatic mask production line,
used to produce disposable medical face masks in mass production. Smart mask
production line can help you produce quickly.

For more information or news about the face mask making machine,please click
here.

https://www.nobelindustrial.com/p , roduct-nbl-4800-ii-high-speed-semi-automatic-
e , xternal-earloop-welding-machine.html

Minimum Order: 1 sets
