Mutoh ValueJET 1638X 64" Large Format Color Printers

Mutoh ValueJET 1638X 64" Large Format Color Printers

Increase your productivity today with the new ValueJet 1638X high speed printer from Mutoh. With its staggered dual head print technology, you can print the jobs of two or three printers using just one ValueJet 1638X.

The 1638X is a four color (CMYK) Eco-solvent printer that produces beautiful, brilliant prints up to 720 sq.ft./hr. in Banner Production mode and up to 1,012 sq.ft./hr. in Banner Draft mode. The ValueJet 1638X is by far the fastest printer in its price range.

All ValueJets are built with Mutoh’s Intelligent Interweave (i²) print technology, which lays down ink in a wave pattern, eliminating banding!

Equip the Mutoh ValueJet 1638X with Mutoh’s SpectroVue VM-10 spectrophotometer for fast, simple and accurate color measuring. With the addition of the SpectroVue you can add process control to your workflow and produce consistent color prints every time with the FREE on-board ColorVerify system.

The ValueJet 1638HD version features the optional heavy duty roll take up and feed system, makingX it a high-volume printer that satisfies the most demanding production house requirements.

With the ValueJet 1638X you can print durable graphics on coated and uncoated substrates up to 64” wide to produce posters, banners, backlit display panels, directional signage, POP displays, floor graphics, vehicle graphics and decals. A one-year on-site warranty is included with the ValueJet 1638X and 1638XHD.

Specifications :

Print Technology Drop-on-demand Micro Piezo Inkjet Technology
Print Head 2 (staggered setup)
Nozzle Configuration 180 nozzles x 8 lines / head
Drop Mass Range (pl) 3.6 to 35.2
Head Heights Low: 1.5 mm
Middle: 2.5 mm
High: 4.0 mm
ValueJet 1638X – Media Specifications
Max. Media Width 1625 mm (63,97”)
Max. Print Width 1615 mm (63,58”)
Max. Media Thickness 0.3 / 1.3 / 2.8 mm *
* : Max. media thickness is specified per head height
Media Measurements * Ø 150 mm / 2” & 3” / 30 kg
* : Standard non-motorised roll-off system
Media Drying System Individually controlled pre-heater, fixer & dryer (30 – 50 °C)
ValueJet 1638X – Performance
High Quality (1080 x 1440) 10.0 m²/h
Quality (720 x 1440) 15.0 m²/h
Quality Production (720 x 1080) 20.0 m²/h
Production (720 x 720) 29.0 m²/h
Speed Production (720 x 720) 36.0 m²/h
Billboard (360 x 720) 48.0 m²/h
ValueJet 1638X – Ink Specifications
Ink Type Eco Ultra / UMS
Ink Volume 220 ml, 440 ml & 1000 ml * / 440 ml & 1000 ml
* : 1000 ml ink bag requires optional adapter
Ink Colours CMYK
Ink Consumption * 8 ml / m²
* : Average ink consumption at @720 dpi – coverage of 67 %
UV durability—without lamination 3 years outdoor *
* : For heavy duty applications where mechanical stress is involved, lamination is required. Stabilisation is required prior to lamination.
ValueJet 1638X – Power Consumption
During Printing < 650 W
In Stand-by 45 W
Warming Up ≤1100 W (main) & ≤ 1250 W (heat)
Power Supply AC 100-120 V / AC 200-240 – 60/50 Hz
ValueJet 1638X – Recommended Working Environment
Temperature 22°C – 30 °C with Δt: max. 2 °C/h
Humidity 40% – 60 % (no condensation) with ΔRH: max. 5% RH/h
ValueJet 1638X – Machine Measurements
Width x Depth x Height 2698 x 885 x 1261 mm
Weight 221 kg


More Information Please Visit our website Official GAOLITOPRINTER for catalog, transaction, full Description, Term and Conditions, best product, or special price.

Minimum Order: 1 sets
