Modicon AS-B838-032 Output Module

Modicon AS-B838-032 Output Module


Part Number AS-B838-032
Manufacturer Schneider Electric
Type I/O Modules
Model # ASB838032
Warranty 2 Year
Terminal Connector AS-8534-000
Description 24 Vdc True High output
Number of Points 32
Operating Voltage 20 ... 28 Vdc
Number of Groups 4
Outputs per Group 8
ON Current
Max. per Point 0.5 A
2.5 A for .5 ms
Max. per Group 4 A
Max. per Module 12 A
Leakage Current 1 mA (typical) @ 30 Vdc
Max. Response Time
OFF to ON 1 ms
ON to OFF 1 ms
Power Required+5 V 160 mA+4.3 V 1 mA-5 V 0 mA
External Power Supply (Excluding field load current) 24 ± 4Vdc, 125 mA
Space Required 1 slot
Weight 2.4 lbs (1.09 kg)
