MMA Welding Machines

MMA welding machines bring low cost and high versatility to site welding, off-
shore, maintenance and repair and many more industries
Also known as shielded metal arc welding (SMAW) or simply stick
welding, MMA is an inexpensive welding process. Using a consumable, flux-
covered electrode and a ground clamp, a short-circuit is intentially made on
the weld piece. An electric arc forms between electrode and workpiece, which
heats up enough to melt both. As the electrode melts, the flux coating on the
electrode develops gas and slag, which help protect the weld pool. The gas
keeps air and other pollutants away, while slag forms on top of the weld pool
to protect the weld seam. The slag cools down and solidifies rapidly,
protecting the weld area after the gas has disappeared. This combination
makes MMA welding ideal for windy conditions (outdoor use) which might effect
other welding processes.
MMA Welding Machines Specification
Technical Parameters MAX ARC 405
Rated Input Voltage (V) 3PH200V~440V±15%
Power Frequency(Hz) 50/60
Rated Input Current（A） 55
Rated Input Power(KVA) 21
No-load Voltage(V) 78
Welding Current(A) 40-400
 Duty Cycle 60%/400A
100%/310A
Efficiency（Rated conditions） ≧0.85
Wire Diameter（MM） 2.5-5.0
Insulation Grade F
Protection Class IP21S
Dimensions(mm) 645x325x680
Net Weight(Kg) 47
