Mitsubishi Q38B main substrate uses transistors for unified output

1 axis, sscnet connected



Control unit: mm, inch, degree, pulse. Number of positioning data: 600 data /
axis. 40 pin connector



Easily realize high-speed and high-precision positioning control. Support
multiple types of positioning control,



Including 2-4 axis linear interpolation, 2-axis circular interpolation, speed
control, speed / position switching control, path control, constant speed
control, etc. In addition, software such as "GX configurator QP" can be used to
facilitate positioning, setting, monitoring and debugging. Q38b saves wiring
through sscnet cable connection, and the total cable distance can be up to 30m



In addition, it supports the absolute position system to determine the origin
position through the origin return data deployment operation.



There is no need to wire the near point stop, etc. Interface module telephone
line connecting peripheral equipment adapter for q2mem memory card with
standard PCMCIA interface. 10BASE-T/100BASE-TX。 Web servo module for RS-232.



The web server module, which uses the Internet / Intranet to perform meta
process monitoring on the programmable controller, uses a PC connected to the
Internet and simply needs to be deployed,



MELSEC can be remotely monitored / operated from any location. The data
recording function can be used to display and collect data. Data can be
recorded at the shortest interval of 100ms. It also has the following
functions.



Send data / alarm notifications via email. Use FTP to transfer / obtain data
files. Display function of event monitoring / history.



User authentication /p filter and other security functions.



Users can customize the creation of web pages. 8-axis, differential driver
output type control unit: pulse.



Number of positioning data: 10 data / axis. Maximum pulse output: 4mpps. 40 pin
connector. Differential output.



Ideal solution for simple multi axis positioning. Perfect match with stepping
motor control. The acceleration and deceleration are smooth and the speed
changes slightly.



Speed up the start-up processing of positioning control. Locate the module.



Open collector output type differential driver output type



It can be divided into two types: open collector output type and differential
driver output type.



The differential driver output positioning module can reliably transmit high-
speed command pulses (up to 4mpps) to the servo amplifier, with a transmission
distance of up to 10 meters, realizing high-speed and high-precision control.



(the maximum command pulse of open collector positioning module is 200kpps.)
Reduce system downtime recovery time.



With simple operation, all data in the CPU can be backed up to the memory card.
Through regular backup, the latest parameters, programs, etc. can always be
saved to the memory card. In case of CPU failure, after replacing the CPU, the
system can be restored through a simple operation through a memory card that
has previously backed up the data



As a result, you don't have to spend time managing backup data, and you can
reduce recovery time in the event of system downtime. Input: 2 channels.



Counter input signal: dc5/12/24v. External input: dc5/12124v. Unified output:
Transistor (drain type).



Used to replace a series large module "ad61". 40 pin connector



It supports high-resolution equipment, pulse input for high-speed and high-
precision control applications, and high-speed counter module product group.
High speed counter module for counting high-speed pulse train. It can be
combined with external encoder for positioning and other control.



The highest counting speed can be switched to count low-frequency pulses from
high-speed pulses to gentle rising / falling edges. Each channel 1 is equipped
with 2 external consistent outputs,



"Consistent output function" and "continuous comparison function" can be
selected according to the purpose to realize the high-speed control of external
equipment. (QD64D2



It provides a variety of functions, such as consistent output test function
(when using continuous comparison function), preset function and latch counter
function. To meet the monthly requirements of various applications. (QD64D2)



The maximum counting speed of input pulse can reach 8mpps (differential input,
2-phase 4-octave). It can be used in semiconductor, liquid crystal
manufacturing and other equipment requiring high position accuracy,



Precise position tracking is performed using a high-resolution encoder.
(QD65PD2)

Minimum Order: 1 pieces
