Mars series (12V/24V/36V/48V,96V,50A-100A) MPPT solar charge controller

Mars outdoor series
MPPT solar charge controller
System voltage: 12V/24V/36V/48V (AUTO); 96V
Charge current: 50A;80A;100A
Max PV input: 150V/300V
Maximum solar panel power: 260W-1680W
Support parallel charging(up to 255 units)
Protection level: IP65
Support remote control&monitor (PC software and APP)
RS485 communication
Suitable for Telecom tower base station
OEM/ODM available, all functions and specifications can be customized.
Main Feature of MPPT solar charge controller Mars(12V24V36V48V,96V,50A-100A)
The tracking efficiency is as high as 99.5%.
Support various lead-acid batteries and lithium batteries.
high-definition LCD high-definition backlight display.
Dual RS485 communication, support integrated monitoring and secondary
development.
IP65 high protection level.

pplications of MPPT solar charge controller Mars(12V24V36V48V,96V,50A-100A)
Household
Th , e household photovoltaic power generation system can meet the electricity
demand in areas without electricity or unstable electricity, and its power
level generally ranges from several hundred watts to several kilowatts.
Base Station
The use of solar energy systems for base stations and communication stations
can not only reduce the overall cost of the system, but also improve the power
supply guarantee rate of the system. It can also be applied to the centralized
power supply of villages, islands and communication base stations to meet the
power demand of the load.
Island Photovoltaic Power Station
There is no mains access or the use of power stations such as geographically
remote areas or islands.

As one of the solar controller manufacturers, we provide 100a mppt solar panel
regulator, 60 amp mppt solar regulator, 60 amp mppt solar controller, mppt 50
amp, solar charge controller mppt 12v, charge controller 50 amp, mppt 48v
charge controller, 36v solar regulator, etc. For more information, please feel
free to contact us!

Minimum Order: 50 pieces
