LW34-12 10KV outdoor SF6 circuit breaker

LW34-12 10KV outdoor SF6 circuit breaker
Product Description
LW34-12 10KV outdoor high voltage SF6 circuit breaker is a new outdoor high-
voltage electrical arcing and SF6 gas as insulating medium. The operating
mechanism points manual storage spring mechanism, motor energy storage spring
mechanism, DC electromagnetic actuator three, all kinds of fish breaker
actuator perfect combination of body as a whole. This product compared to other
fish 10kV class outdoor circuit breakers, has a simple structure, high arcing
and insulation performance, small operating power, high ratings, long life and
no maintenance cycle and other significant advantages. Use of this product will
not only reduce the area. Reduce project cost and eliminate the risk of fire,
and can greatly improve the reliability of the power system.
Technical parameter
Rated
voltage
(kV) Rated
current
(A) Rated
short-circuit
breaking current
(kA) Rated
short-circuit
current
(kA) Rated peak
withstand
current
(kA)  Rated short
time withstand
current
(KA) Rated short
duration
(S) Rated
short-circuit
current
breaking times Weight
(kg)
10 400
630 6.3
8
12.5 16
20 16
20 6.3
8
12.5 4 30 130

Click to Enlarge
