LW Vertical in-line sewage drainage pump

LW,WL Vertical pipeline sewage pump not clogging centrifugal pump:

LW Vertical not-clogging sewage pump is used to transfer the waste water with
fiber diameter 5 times as pump diameter or the solid particles diameter 50% as the
pump diameter. LW vertical not-clogging sewage pump adopts a unique single
(double) channel impeller and improves the sewage discharge for the not-clogging.

LW sewage pump has two structural forms. One is the motor and pump directly
connected coaxial and the other is the use of coupling connection. The motor
adopts a standard vertical motor. Its structure diagram is as follows. Each
structure form has two base connection forms. One is the horizontal suction of the
inlet and has the function of turning Angle. It can be used according to the
requirements .Even the outlet Angle can be set to 0., 90., 180, 270, easy to
connect the pipeline and the other is the inlet axial suction and belongs to
vertical installation.

Characteristics:

1. The not-clogging impeller with big flow channel can transfer the waste water
with fiber diameter 5 times as pump diameter or the solid particles diameter 50%
as the pump diameter.

2. The motor with high efficiency and energy-saving

3. Single face mechanical seal( tungsten carbide material has the advantages of
wear-resisting and corrosion-resisting etc) can continuously work more than 8000
hours.

4. LW pump is directly connected with motor by the shaft and the equipment
structure is compact and discharging performance is steady.

5. The advanced mode with high efficiency and low noise etc.

6. When the motor is with protective sleeve and the pump can be used outdoor
without pump room. So the use cost for the pump is economic.

7. LW pump and motor is as the whole structure for the convenient installation.

Application:

Irrigatio , n and drainage fields and various water conservancy projects, all kinds
of farms, slaughter houses, slaughter yard, septic tank, etc and Municipal
engineering, construction site.

Performance range for LW pump:

Flow rate:5 to 3600m3/h

Head: 5 to 60m

Speed: 980 to 2900r/min

Pump inlet and outlet: φ25 to φ500

Working pressure:≤1.0MPa

Minimum Order: 1 sets
