ISO4210 IEC Test Equipment Electric Bicycle Concrete Road Pavement 200V Tes

Standard:GB17761-2018 Clause 7.2.1,Clause 7.2.2 , Clause 7.2.4, ISO4210.

Application: This tester is used for the detection of electric bicycle speed
limit and pedal riding ability. According to the relevant requirements of
GB17761-2018, GB3565-2005 and other standards, the safety performance and
energy consumption of electric bicycles and other products are tested. The
data can be stored and transmitted. The test parameters include
deceleration, speed, time, distance, force, current, voltage, and so on.

Operating conditions:

1,Test environment: -5 °C ~ 35 °C, wind speed <3m / s.

2,Test road:

1) Road pavement: concrete road pavement.

2) Road size: 3m (length) * 2m (width) * 20cm (thickness).

3) Friction coefficient between dry road surface and electric bicycle tire:
minimum 0.5.

3,Cycling staff weight: total mass ≤ 75Kg.

Parameters:

1,It can test the safety performance of electric bicycle according to the
requirements of GB17761-2018, voltage collection range: 24V/36V/48V,
48V/60V/72V.

2,The electric bicycle braking performance test can be carried out in
accordance with the requirements of GB3565-2005.

3,The driving mileage test can be carried out as required.

4,A variety of test methods to meet the vehicle speed measurement of the
vehicle's static state.

5,The electric bicycle safety performance test can be carried out in
accordance with the requirements of GB17761-2018.

6,Instrument accuracy: ±2% (provided in the response file to provide proof
of the technical parameters (manufacturer color pages or manuals or product
manuals)).

7,Measuring range:

NO. Item Range
1 Speed 0.5～200.0km/h
2 Distance 0～20000m
3 Time 0～99999s
4 Force hand brake 0 ~ 200N
5 Current 0～100A
6 Voltage 0～200V

(Provided materials (manufacturer color pages or instruction manuals or
product manuals) that reflect this technical parameter are provided in the
response file)

8,Test parameter resolution:

NO. Item Resolution
1 Speed 0.01km/h
2 Distance 0.01m
3 Time 0.01s
4 Force 0.1N
5 Current 0.1A
6 Voltage 0.1V

The main configuration:

1,1 set of professional version test software

2,Control display device 1 PC

3,GPS sensor 1 Set

4,Speed sensor 1 Set

5,Brake operating force component 1 Set

6,Current sensor 1 Set

7,Control computer 1 PC

8,Brake spray device 1 Set

9,Test accessory 1 Set

10,Import VBOX II SX (RLVB2SX) road vision 1 PC

ISO4210 IEC Test Equipment Electric Bicycle Concrete Road Pavement 200V
Tester With Friction Coefficient Of 0.5 0
