Injection Molding TPEs

Injection-grade TPE

Products Characterization:

High fluidity. Soft-touch. Overmolding compatibility with TPE/PP/PE cable.

Application

TPE wire sheaths. Overmolding PP/PE. Stationery. Tool grip. Sporting equipment

TPE injection guidance

1. Previous drying of the product 2 hours at 80℃

2. Medium injection pressure & speed

3.Typical barrel temperature suggested


C1 C1 C3 NOZZLE MOLD
170-190 ℃ 180-200 ℃ 190-210 ℃ 190-210 ℃ 30-60 ℃
Technical Data of Injection Molding TPEs
Technical Data Sheet Model
Material Properties Test Standard Test Condition Unit 2575F-
RSS-1006S
General Characteristics Material Category - - -
Appearance(Light/Semi-matte/Frosted) - - -
Extrusion/Injection - - -
Physical Characteristics Hardness ISO 48 15S Shore A 75
Proportion ISO 1183 - g/cm³ 0.963
Melt Index ISO 1133-1:2011 190℃/2.16kg g/10min 64.2
Brittle Temperature ISO 812 - ℃
Mechanical Properties Elongation ISO37:2017 200mm/min %
450
Tensile Strength ISO37:2017 200mm/min Mpa 6.65
Tearing Strength ISO34-1:2015 500mm/min KN/m
Hot Air Aging Elongation Retention Rate ISO37:2017 - %
Tensile Strength Retention Rate ISO37:2017 - %
Electrical Performance Volume Resistivity ASTM D257 - Ohm-cm
Permittivity ASTM D150 - -
Combustion Performance Vertical Burning Test UL 94 3.0/6.0mm -
Oxygen Index ASTM D2863 - %
Feature

As one of the most plastic compound suppliers, we provide tpu material
injection molding, thermoplastic compound, atp polymer, tpe elastomero
termoplastico and etc. For more information about tpe manufacturing process and
tpe process, please feel free to contact us!

Minimum Order: 500 kilograms
