Industry Aluminium Foil

Industry Aluminium Foil
One of the most important applications of Industrial Aluminum Foil is
insulation. For example, it is used as an insulation layer for pipelines and
pipelines
Foil shielding is a type of shielded cable that uses a thin layer of aluminum
and polyester backing to wrap the cable to improve durability. The foil shield
works in series with the tinned copper shielding wire to ground the shield.

Jumbo Roll Aluminium Foil Technical Data:
Product Industry Aluminium Foil Contract No.
Dimension (mm) 0.06-0.2 Alloy & Temper 8011-O
Techuique Standard GB/T3190--1996/EN

Chemical Composition(%)
  Si Fe Cu Mn Mg Cr Ni Zn Ti
Others Al
Standard 0.20~ 0.35 0.1 0.1 0.45~0.9 0.1 -
0.1 0.1 0.15 Rest
0.6
Notice:Aluminum sheet not contains Pb、As and other Virose elements
Mechanical Property
  State Tensile Strength（Mpa） Strength(Mpa) Elongation% Cup
Bulge
Standard T6 ≥205 ≥180 ≥8 -
