Industrial Wired Dust Detector

Product Name: Industrial Wired Dust detector
Model No: SS-ENVIR-DUSTWD4P
Product Description:
The explosion-proof dust concentration detector is developed and produced
according to industrial design standards, which is suitable for continuously
monitoring the total dust concentration in the atmosphere in coal mines and
other explosive hazardous working environments. To meet the needs of
enterprises to monitor the dust concentration in the workplace, with real-
time alarm function, can accurately and timely reflect the dust pollution
status in the dust workplace.
The dust concentration detector is composed of sampling head, detection
device, single chip microcomputer system and pumping system. It has the
characteristics of easy to carry, fast and accurate measurement, high
detection sensitivity, stable performance and simple maintenance. Thanks to
the use of new technologies such as laser technology and highly reliable
pumping system, the sensor is more high-quality and technologically superior.
With explosion-proof function, can be directly installed in the explosive
area for use. Stable performance, easy installation and maintenance, widely
used in steelmaking, power generation, petroleum, chemical industry,
medicine, building materials processing, coal mining, mining, manufacturing,
packaging and other places. Detection of bag damage, recovery of powdery
materials, monitoring of total product delivery, or monitoring of boiler
smoke emission concentration of various sizes and fuels.

Main Features:
1.The rated working current is small, which greatly reduces the burden of the
total power supply on site;
2.Wide input voltage range, the instrument can work normally within the input
voltage of 12V ~ 24V DC(intrinsic safety power supply);
3.Absorbs and digests the advanced dust detection technology at home and
abroad, uses the light scattering principle to detect dust, and calculates
the detection data by the microprocessor to directly display the dust mass
concentration and convert it into data signal output;
4.Infrared remote control is used to adjust the sensor parameters to realize
the adjustment without opening the cover, which is easier to adjust and
calibrate.

Main Application:
With explosion-proof function, can be directly installed in the explosive
area for use. Stable performance, easy installation and maintenance, widely
used in steelmaking, power generation, petroleum, chemical industry,
medicine, building materials processing, coal mining, mining, manufacturing,
packaging and other places. Detection of bag damage, recovery of powdery
materials, monitoring of total product delivery, or monitoring of boiler
smoke emission concentration of various sizes and fuels.

Technical Parameters:
1.Detection principle Principle of light scattering detection
2.Power Supply DC24V
3.Measuring object Workplace dust detection, dust environment monitoring
4.Measuring range 0.1 mg/m³～1000 mg/m³
5.Measurement error ±10%
6.repeatability ＜5%
7.Operating temperature 0℃～40℃
8.Working humidity ＜95%RH
9.Atmospheric pressure 86kPa～106kPa
10weight ≤2.0kg
11.Explosion-proof mark Combustible dust environment ExibD21 IP65 T120℃
12.Explosive environment ExibII B T4 Gb
