Industrial Small Capacity Dairy Homogenizer For Milk Processing Types

Small Capacity Milk Processing Types dairy homogenizer 500 L/H 70 Mpa 11 KW



Homogenizer Working Theory:



When product is flowing through the adjustable valve, the particles or droplets
present in mixed fluids with high pressure will be subdivided into the very
smallest sizes ( φ =0.01 - 2 μm, average φ ≤ 1 μm) because of pressure
decrease, expansion, explosion, cutting and high-speed impacting etc., then the
emulsions or dispersion could be produced. Through homogenizing the stablity,
easy-absorb, long-life, taste and color etc. of product could be realized.
Therefore, homgenizer has been recognized as the best equipment of the
dispersion and emulsion in the century.



Industrial Small Capacity Dairy Homogenizer For Milk Processing Types 0





Main technical parameters:



Model

SRH500-70

Rated flow: L/H

500

Max pressure: Mpa

70

Normal working pressure: Mpa

0-56

Inlet pressure: Mpa

0.2-0.3

Adaptable material feeding temperature / viscosity

100℃/≤1000CP

Rated motor power: KW

11

Size: cm

125*85*115

Weight: KG

800

Lubricating oil

L-HM100 OR Mobil SHC627(ISO VG100)

Housing Material

Stainless steel

Plunge Sealing Material

packing

Pressure gauge

Diaphragm

Support material

shaped steel



Applications:



1.Food and Drink

Enzymes, dressing, tomato sauce, fruit paste, butter oil, drink, dairy drink,
Ice cream, baby food, chocolate, flavors and fragrances, milk powder.

2.Chemical

Disinfectants, emulsifiers, fuel oil, insecticides, oants, oil emulsions,
silicone emulsions, wax emulsions, lubricants, resins/rosins, latex, viscosity
Improvers.

3.Biotechnology

Cell disruption of yeast, E.coil other bacteria and algae.

4.Pharmaceutical

Antibiotics, skin cream, intravenous, emulsion, ointments, tablet coatings,
lipostiomes

5.Cosmetics

Hair products, skin creams, lotions, perfumes, shampoos and conditioners.



Types of Homogenizer:



1.Manual Operating Homogenizer

Two- stage homogenizer system with manual pressure adjustment is easy to use.
It is your economic choice.

2.Hydraulic Operating Homogenizer

The hydraulic control system is developed to adjust the homogenizer pressure,
and it is easy to upgrade to remote control system by changing to Proportional
valves.

3.Pneumatic Operating Homogenizer

The pneumatic control system is developed for the homogenizer, and it is easy
to upgrade to remote control.

4.Large Capacity Homogenizer

This machine has five plungers with the maximum flow reaching 30000L/H. The
hydraulic end adopts the split structure which facilitates assembly and
disassembly. The pressure adjustment can adopt manual or hydraulic mode.

5.Laboratory Homogenizer

Capacity: 60L/H Max Pressure</=70MPa

Minimum Sample Volume: 200ml



Qustions you may have about our company:



1. Are you a new company?

Actually, we have 20 years experience specialized in high pressure homogenizer.
We are the most famous manufacture of high pressure homogenizer in China and we
have very good reputation in China. Now we want to develop new area and bring
high quality homogenizer with competitive price to overseas.



2. Do you have different pressure from the mentioned one?

Yes, we have different pressure homogenizer from 20-150Mpa. And the capacity
could be different, too. You can tell us the requirement of the pressure and
capacity, our technician will check if we can meet your demand. And our sales
will offer you the best service and rather competitive price.



3. What’s the meaning of your Model No.?

We think example can make you understand more quickly. For example, our model
SRH1000-30, SRH means SAMRO Homogenizer, 1000 means the capacity of each hour
is 1000L, 30 means the max pressure of this model.



We are a 20 years original specialized factory here. Leave us an inquiry to
know more details according to the different models you need.

If you have any special request, please kindly let us know, we will try our
best to meet your demand.
