High Quality NBR Material COMBI Black Original Agricultural Oil Seal

COMBI oil seal
The combination seal composed of standard SC/TC/DC shaft sealing ring and
polyurethane anti pollution guide plate is an indivisible entity connected by a
metal frame, especially with the huge ability to form an anti pollution
barrier. The material and design of this polyurethane cooler component form a
barrier to external impurities, making the combination seal highly reliable.
Application scope: Combination oil seals suitable for extreme wear
applications. The oil seal and dust seal are combined in a metal casing,

Product features:
Design: Special model for consultation
It is composed of a regular oil seal and another auxiliary sealing ring, mainly
to prevent external pollutants from entering.
The sealing lip is equipped with springs
Equipped with dust lips
Mainly used for various purposes with high pollution, such as transmission
shafts for off-road vehicle axles.
When subjected to significant rotational or translational motion, it is best to
use it instead of a box type combination oil seal

Product advantages:
Long working life
Optimized design for sealing and dustproof lips, with strong resistance to
pollutant invasion
Performance in preventing the intrusion of external pollutants
Extremely high performance in preventing external pollutants from invading,
especially suitable for preventing dry pollutants.

Recommended applications:
Agricultural machinery
Driving parts of agricultural or industrial machinery
The driving part of rotating moving parts, or the motion axis that sometimes
experiences dry friction.

Material formula:
Nitrile rubber: code 75 NBR 106200; Color: Black; Hardness: Shore A 75 degrees.
Fluorine rubber: code 75 FKM 595; Color: reddish brown; Hardness: Shore A 75
degrees.
Metal frame: Non alloy steel DIN 1624-EN10139
Spring: Spring steel DIN 17223
Pollutant scraper: Polyurethane (AU)

Cassette seals are sophisticated sealing solutions designed for superior
system reliability and extended lifespan. Comprising a sleeve, a sealing lip
with a spring, and multiple anti-dust lips integrated into a labyrinth system,
these seals offer robust protection against external pollutants. Their advanced
design not only enhances reliability but also reduces the need for shaft
maintenance during replacement.
