HIFU System

Professional HIFU-Q3 New arrival skin tightening focused ultrasound anti-
wrinkle face hifu 7d facial and body

Model:HIFU-Q3
Working Theory:

High Intensity Focused Ultrasound (HIFU) directly delivers heat energy to skin
and subcutaneous tissue that can stimulate and renew the skin's collagen and
thus consequently improving the texture and reducing sagging of the skin. It
literally achieves the results of a facelift or a body lifts without any
invasive surgery or injections, moreover, an added bonus of this procedure is
that there is no downtime. This technique can be applied to the face as well as
the whole body, and also, it works equally well for people of all skin colours,
in contrast to that of lasers and the intense pulse lights.
HIFU machine is a non surgical and a non laser procedure that directs high
intensity focused ultrasound, also known as HIFU knife into the deep skin layer
in order to gently heat the tissue to lift and tighten aged skin without any
incisions of disrupting skin surface. HIFU technology is able to transfer the
heat energy into 3-4.5mm under the surface of the skin. It will heat the SMAS
up to 60-70 temperature the raises thermal coagulation point which accelerates
skin rejuvenation process and maximizes tightening effect of the skin layer.
How it works?

Advanced High Intensity Focused Ultrasound(HIFU) adopts technology which is not
like lasers, radio frequency, surgery and other technologies, HIFU is non-
surgical.
HIFU steer around the surface of the skin to deliver the precise and fractional
of ultrasound energy at the right depths(i.e.3.0mm/ 4.5mm SMAS layer) without
damaging or disrupting the epidermal tissue of skin and the right temperature
65~70ºC.This energy stimulates the new collagen to reproduction, which
rejuvenates the skin leading to a more youthful and bright or to sharpen
contouring. HIFU is especially suitable for treating sagging skin with
reasonable thickness as well.
Machine Advantages:
1. Non-Invasive treatment both for face and body with different cartridge;
2. Adopts HIFU technology, the temperature of focused ultrasound can reach 65
ºC to 100 ºC;
3. Security control system can distinguish different cartridge automatically;
4. Special Cartridge connect method make sure no energy loss during the
treatment;
5. Professional mode with free setting parameter and memory function for saving
data;
6. Smart mode with limited energy and preseted parameters for simple and safe
treatment;
7. Uniform energy distribution brings better clinical effect and quickly
treatment;
8. Cartridge with long life span of 10,000 shots;
9. HIFU-Q3 has 2 extra transducer 8mm and 13mm,which give you an option for
body treatment: body tightening ,lifting and slimming.

Technical Specifications:
Model HIFU-Q3
Machine Type Anti-wrinkle Machine
Operation principle Ultrasonic
Voltage Input AC220V-230V/50-60HZ AC100V-110V/50-60HZ
Output Power 0.1~2.0J(0.1J/step)
Space Range 1.0~4.0mm(0.5mm/step)
Length 5.0~25mm(1.0mm/step)
Screen Size 15" TFT LCD touch screen
HIFU Cartridge 3 heads for standard:1.5mm, 3.0mm, 4.5mm;
2 heads for optional: 8mm,13mm.
Cartridge Shots 10,000shots/catridge
Gross Weight 20.0KG
Packing Size(size) 480*570*550 mm

HIFU Cartridges:
1. DS-4.5mm: To transmit high- energy focused ultrasound to the skin,
subcutaneous tissue, the ultrasound to penetrate the skin to a depth of 4.5mm,
direct subcutaneous SMAS layer, forming "heat coagulation" regional, targeted
to thicker skin, such as cheeks, etc.
2. DS-3.0mm: To transmitting high frequency into the dermis layer of the skin
tissue,the ultrasound to penetrate the skin to a depth of 3.0mm,is responsible
for activating the skin's dermal layer of collagen,effectively enhance the
effect of the consolidation of the outline,but also improve large pores and
reduce the appearance of wrinkles.
3. DS-1.5mm: To transmit high-energy focused ultrasound to the epidermis
tissue,the ultrasound to penetrate the skin to a depth of 1.5mm,is responsible
for activating the skin epidermis in thinner tissue.
4. DS-8.0/13.0mm: To transmit high intensity focused ultrasound activating in
depth of 8.0mm/13.0mm. targeted to thicker skin, such as thighs, buttocks.

Minimum Order: 1 sets
