HEDUN Vertical Froth Pumps

HEDUN Vertical Froth Pumps
The pump head use double shell structure, the flow-parts use hard nickel, high
chromium or rubber material, and its driving section is universal with SP(R)
type pump. Hopper charging box use steel plate structure, liner plate can be
covered if the conveying media required, and the pump outlet opening position
can be interval changed by 45°. This series of froth pump can effectively
eliminate the foams and bubbles out of the slurry during the operation. Even
the feed-in material is not enough, the pump can still work normally.
odel Power P（KW） Capacity Q(m³/h) HeadH(m) Speed n(r/min)
Eff. % Inlet dia.(mm) Outlet dia.(mm)
HDF2Q 3-15 6-43 6-30 800-1800 45 100 50
HDF3Q 3-18.5 23-78 5-28 700-1500 55 150 75
HDF4R 5.5-37 33-187 5-28 500-1050 55 150 100
HDF6S 15-75 80-393 5-25 250-680 55 200 150
HDF8S 37-110 126-575 5-26 350-650 55 250 200

Application
Specially for delivering the frothy slurry of abrasion in flotation process in
mines, metallurgy, chemical process, coal industries, etc

The Vertical Froth pump is suitable for:

The Vertical Froth Pump is ideal for all applications involving handling of air
entrained slurry, such as flotation froth in base metal concentrators,
phosphate and apatite washing plants and calcium carbonate upgrading plants

The pump can be used as a mixing and distribution unit, where dry powder has to
be mixed (and wetted) with water.

Application field:

Iron Ore Dressing Plant

Copper Concentration Plant

Gold Mine Concentration Plant

Molybdenum Concentration Plant

Potash Fertilizer Plant

Mineral Processing Plants

Minimum Order: 1 sets
