Halogen Free Flame Retardant Heat Shrinkable Sleeves Tubing PE 1.0 - 250mm

Flexible Flame Retardant Heat PE Shrink Tube For Wires With Logo Printing

Halogen Free Flame-retardant Heat Shrinkable Tube

Model Number: HS-125H
Working temperature: -45ºC ~ 125ºC

Structure
Halogen free flame-retardant heat shrinkable tube is made of eco-friendly cross-
linking polyolefin material under irradiation. It has environment-friendly,
flexible, flame retardant, quick shrink and stable performances. Also, it has
electrical insulation, welding point anticorrosion and antirust and mechanical
performances. It has passed UL, RoHS, Reach certifications for 300V and 600V.

Usage
It is mainly used in electronics, telecommunication, automobiles,shipping and other
manufacturing industries.

Characteristics

Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable
performance
Shrink ratio: 2:1
Shrink temperature: 84ºC ~ 120ºC
Property Unit Test Method Standard
Tensile Strength MPA ≥10.4(before aging) GB/T 1040
≥7.3(after aging) 158ºC*168h
Breakage Elongation (%) % ≥200(before aging) GB/T 1040
≥100(after aging) 158ºC*168h
Heat Shock - no sticking & no cracking 250ºC*4h
Cold Blend - no cracking -30ºC*4h
Breakdown Strength KV/mm ≥15 GB/T 1408
Dielectric Withstand 600V - Pass no breakdown for 2500V, 60s
300V - Pass no breakdown for 1500V,60s
Volume Resistivity Ω. cm ≥1×1014 GB/T 1410
Corrosion Performance - pass 158ºC*168h
Copper Stability - pass 158ºC*168h
Flammability - pass VW-1
