GWM-9020B Digital Stepping Motor Coil Winding Machine

SPECIFICATION:
Wire Size:0.05-1.1mm
Max Speed:1500rpm
Min.Finished I.D.:3mm(will be different by shuttle size and coil height)
O.D.Range:8-60mm
Winding Motor:1/2HP DC motor
Weight:70kgs
Spreading Motor:Stepping Motor
Dimension:600*620*550mm
Memory Capacity:999 sequences
Power source:AC 220V/110V(50/60MHz)
Min.wire size:According to the machine head and shuttle size

FEATURES:
Digital Stepping Motor Coil Winding Machine has Hi-tech shuttle for highest
efficiency.
Digital Stepping Motor Coil Winding Machine has separate speed controls for
loading and winding.
Digital Stepping Motor Coil Winding Machine has accurately count length of
loading by limited-switch.
Accurately count turns of winding by photo-electricity sensor
Programmable winding direction, winding returns range (Turns or Angle) and
segment winding angle
Accurately wire spacing by programmable controller
Memory capacity accommodates 999 sequences of parameters with off-power
memory retention for more than one year.
Automatic wire clamp and cut system, layer winding, material unloading and
cleaning of the tool during each cycle.
Optional release agent dispensing to aid removal of the coil from the
tooling.
Fine programmable pitch control enabling precise layer winding.

ADVANTAGES:
One year guarantee for whole machine
We can design and develop special machine based on your request
We can train customer how to operate and repair equipment
We supply full and quickly services when you use our products.
Corrosion resistant,High tensile strength,Easy to use
Optimum performance oriented

APPLICATION:
Toroid Winding Machine is the best suited to toroidal inductor, toroidal
transformers,toroidal current transformers,toroidal coil, toroid choke
coil, power inductors,UPS inductor,converter inductor and heavy toroidal
core etc.

PRACTICAL APPLICATION :
TRAINNING CUSTOMER TO OPERATE WINDING MA , CHNE :
1.All service engineers with 10 ye , ars experience are gotten special technol
, ogy training, who can deal with various bre , akdown problem.
2.Guide the user to use a , ccurately and how to maintain the Digital Stepping
Motor Coil Winding Machine.
Provide free consultation about pr , oduction process technology of electronic

Minimum Order: 1 pieces
