GW-9761i Digital CNC Wire Coil Winding Machine

SPECIFICATION:
Spindles:1
Spread Motor:4-Phase stepping Motor
Wire diameter:0.02-0.8mm
Max Speed:6000rpm
Spread Pitch:0-9.999mm
Memory:999 Sequences
Spread Width:100mm（Max）
Power Source:AC 220V/110V±10%,50/60MHZ
Winding Width:150mm（Max）
Weight:45×67×10
Main Motor:1/2HP DC Motor
Dimension:45

FEATURES:
The ceramic rollers of Digital CNC Wire Coil Winding Machine prevent enamel
from high temperature.
Digital CNC Wire Coil Winding Machine has multiple spindles synchronal
winding for highest efficiency.
Digital CNC Wire Coil Winding Machine has more convenience by using foot-
switch.
Nine winding parameters and 5 options can be independently assigned for
each step.
Memory capacity accommodates 999 sequences of parameters with off-power
memory retention.

ADVANTAGES:
The position of the winding point can be inputted by teaching, and the
current position of the spool can be displayed.
Adopt multi - wire rows, four different diameters can be installed at the
same time.
It can be replaced to make double axis synchronous winding machine.
The winding point, width, line distance and speed can be set in sections to
achieve the purpose of multi-section and multi-speed.
Single axis large torque Digital CNC Wire Coil Winding Machine is widely
used in rectifier and other medium coils, solenoid valves, high-power
transformers.
The program can be changed according to the need to achieve multi-function.

APPLICATION:
Typical applications for high torsion parallel spindle winding Machine with
a single wire size, include the manufacture of gas ignition coils,
solenoids, relays, motors and many forms of sensor coil in small and medium
batch quantities.It is ideal for use in the production of small inductors,
particularly bobbins wound with a single wire size and high turns count.
The high maximum winding spindle speed (up to 6000 rpm) enables coils with
a high turns count to be wound in a short cycle time.
