GW-9720 Automatic Motor Winding Machine

SPECIFICATION:
Spindles:1
Max Speed:3000rpm
Wire diameter:0.03-1.6mm
Memory:99 Sequences
Main Motor:1/8HP DC Motor
Power Source:AC 220V/110V±10%,50/60MHZ

FEATURES:
Automa , tic Motor Winding Machine has microprocessor design ,easy for
program-setting handing.
Setting winding direction ,brake time for each step independently
Automatic coil winding machine is easy to use VR-switch to adjust the speed
of winding.
Automatic wire clamp and cut system, layer winding, material unloading and
cleaning of the tool during each cycle.
Automatic Motor Winding Machine through programmable pitch control enabling
precise layer winding.

ADVANTAGES:
Automatic Motor Winding Machine adopts multi - wire rows, four different
diameters can be installed at the same time.
Single machine can finish winding and insulation, acetic acid tape winding.
It can be replaced to make double axis synchronous winding machine.
The winding point, width, line distance and speed can be set in sections to
achieve the purpose of multi-section and multi-speed.
Single axis large torque digital parallel winding machine is widely used in
rectifier and other medium coils, solenoid valves, high-power transformers.
The program can be changed according to the need to achieve multi-function.

APPLICATION:
Typical applications for high torsion parallel spindle winding Machine with
a single wire size, include the manufacture of gas ignition coils,
solenoids, relays, motors and many forms of sensor coil in small and medium
batch quantities.It is ideal for use in the production of small inductors,
particularly bobbins wound with a single wire size and high turns count.
The high maximum winding spindle speed (up to 6000 rpm) enables coils with
a high turns count to be wound in a short cycle time.

PRACTICAL APPLICATION :

TRAINNING CUSTOMER TO OPERATE WINDING , MACHNE :
1.All service engineers with 10 , years experience are gotten special technol ,
ogy training, who can deal with various

Minimum Order: 1 pieces
