Graphite hot plates with anti-corrosion coating, resistant to high temperat

DBF temperature-controlled electric hot plate, also known as anti-corrosion
electric hot plate, has a Teflon-coated non-stick surface and is not affected
by strong acids and alkalis. It is an electric hot plate used for sample
heating, digestion, evaporation, boiling and acid removal experiments.
It can be used with our Teflon series such as beakers, crucibles, digestion
tubes, sample dissolving tanks, digestion tank inner cups, etc., and the effect
is good.
It can meet the reagent heating needs of chemical laboratories in different
industries such as physics, chemistry, biology, environmental protection,
pharmaceuticals, food, beverages, teaching, and scientific research.
Technical parameters of anti-corrosion electric heating plate
Model: DBF type
Operating area (mm): 600 * 400mm, 400 * 300mm, 500 * 250mm, 450 * 350mm, etc
Heating method: Electric heating PID digital display
Working temperature: 220 ℃
Temperature control accuracy: ± 1 ℃
Surface anti-corrosion of heating plate: PFA coating
Heating plate material: exquisite aluminum alloy/graphite
Rated voltage: 220V (adjustable according to region)
Continuous working time:>48 hours
Supporting products: Crucible/beaker/PFA vials
characteristic:
1. PFA Teflon coating, anti-corrosion cast aluminum heating plate heats up
quickly;
2. The board and the control box can be made into two parts, so that the acid
mist during the experiment will not corrode the components in the control box,
thereby increasing the service life and processing multiple samples at the same
time without cross-contamination;
3. Customizable time setting function and segmented temperature control;
4. The exposed part of the power cord is wrapped with PFA tubes to further
prevent acid gas from corroding components;
web: https://www.njbinglab.com

Minimum Order: 3 pieces

Click to Enlarge
